技 术 规格: |
|
Model NO. | LB-MS09 |
Laser Diode | Diode-pumped (DPSS) laser diode; |
Laser Color | Multi-color |
Laser Wavelength | Red638nm、Green 520nm、Blue447nm |
Laser Power | Red：200mw Green:100mw Blue：500 mw |
spot size | 4mm |
Scanning System | Scanning speed 30kpps; scan angle of ± 30 degrees; Closed-loop high-speed scanner; |
Control System | US Pangolin System;PC，DMX512，AUTO mode |
security project | lightning protection；rain-proof；constant temperature；over voltage protection |
Application Areas | KTV rooms、Family parties..etc |
Cooling Method | Air-cooled |
Power Consumption | AC110V-240V;50-60HZ/500W |
Dimensions | M180mm x H180mm x D230mm |
N.W. | 5kgs |
